Component identification 12
Item Description
1
Slot 6 PCIe2 x4 (1)
2 Slot 5 PCIe2 x8 (4,1)
3 Slot 4 PCIe3 x16 (8,4,1)
4 Slot 3 PCIe3 x16 (16,8,4,1)
5 System maintenance switch
6 Slot 2 PCIe3 x16 (16,8,4,1)
7 Slot 1 PCIe3 x8 (4,1)
8 Processor 2 DIMM slots
9 Processor socket 2
10 System battery
11 Processor 2 power connector
12 Processor socket 1 (populated)
13 Processor 1 DIMM slots
14 Internal USB connector
15 Fan connector 3
16 SD card connector
17 Internal USB tape drive connector
18 Processor 1 power connector
19 SATA connector 2
20
SATA connector 1
21 Mini-SAS connector
22 System board power connector
23 Fan connector 2
24 Front panel connector
25 Front panel connector
26 Fan connector 1
27 Ambient temperature sensor connector
28 Redundant power supply connector
29 Cache module connector
30 TPM connector
31 NMI header
System maintenance switch
The system maintenance switch (SW2) is a twelve-position switch that is used for system configuration.
Position Description Function
S1 iLO security
override
Off = No function.
On = Override enabled.
S2 Configuration
lock
Off = System configuration can be
changed.
On = System configuration is locked.
S5 Password disable Off = Power-on password enabled.
On = Power-on password disabled.
