Recognizing preset display resolutions
The display resolutions listed below are the most commonly used modes and are set as factory defaults.
This display automatically recognizes these preset modes and they will appear properly sized and
centered on the screen.
Preset display modes
Table B-2 Factory preset display modes
Preset Pixel format Horizontal frequency
(kHz) Vertical Frequency (Hz)
1 720 x 400 31.468 70.1
*2 640 x 480 31.469 59.94
3 640 x 480 37.5 75
*4 800 x 600 37.879 60.317
5 800 x 600 46.875 75
6 832 x 624 49.725 74.55
*7 1024 x 768 48.363 60
8 1024 x 768 60.123 75.029
*9 1280 x 720 44.772 59.855
*10 1280 x 1024 63.981 60.02
11 1280 x 1024 79.98 75.02
*12 1680 x 1050 65.290 59.954
*13 1920 x 1080 67.5 60
1 to 13 RGB mode
* HDMI/DisplayPort mode
DTV mode
HDMI/DVI
(DTV)
DisplayPort
480i x x
480p o o
576i x x
576p o o
720p o o
