Connect an HDMI to DVI signal cable to the HDMI/DVI port on the display, and then to the
DVI port on the media player/computer.
For AUDIO input from the media player/computer (this is only needed with DVI input signal
connections), connect the RCA-PC audio cable (cable not included) to the display and to the
Audio OUT ports on the media player/computer, then connect the display power cord.
NOTE:
Use shielded signal interface cables (D-sub 15 pin cable, DVI cable) with ferrite
cores to maintain standard compliance for this product.
Figure 3-30
Connecting the HDMI to DVI signal cable
2.
Select an input signal.
Press the INPUT button on the remote control, select the HDMI/DVI input signal, and then press
the OK button to save.
Or, press the
INPUT
button on the back of the display, select the HDMI/DVI input signal, and
then press the
AUTO/SET
button to save.
