OSD menu selections
The following table lists the On-Screen Display (OSD) menu selections and their functional descriptions.
Icon
Main menu
Submenu
Description
Aspect Ratio
Selects from the following screen image sizes:
●
16:9—Widescreen mode.
●
1:1—Picture format is 1:1 aspect ratio.
●
Just Scan—Allows you to enjoy the transmitted data fully
without any images cut off. (This menu is activated only in
720P, 1080P, 1080i (HDMI/DVI-DTV, DisplayPort-DTV).)
●
Original—Picture format is automatically set to 16:9 or
4:3 aspect ratio according to input signal.
●
4:3—Picture format is 4:3 aspect ratio.
●
14:9—Programs are viewed normally in 14:9 with black
bars added to the top and bottom. The 4:3 programs are
magnified on the top/bottom and left/right sides.
●
Zoom—4:3 programs are magnified until they fill the
16:9 screen. The top and bottom will be cut off.
●
Cinema Zoom 1—Picture format is 2.35:1 aspect ratio,
extending the picture horizontally with black bars added
to the top and bottom.
Energy Saving
Select from the following screen brightness levels:
●
Off—100% light
●
Level 1—80% light
●
Level 2—60% light
●
Level 3—40% light
Picture Mode
Select from the following screen presets:
●
Vivid—Select to display with brightest image.
●
Standard—The most general and natural screen display
status.
●
Cinema—Lowers brightness by one level.
●
Sport—Displays with a soft image.
●
Game—To enjoy dynamic image when playing a game.
●
Expert 1 and Expert 2—Allows user-defined settings:
◦
Backlight—Controls the brightness of the screen,
adjust the brightness of the LCD panel.
◦
Contrast—Adjusts the difference between the light
and dark levels.
◦
Brightness—Adjusts the brightness of the screen.
◦
Sharpness—Adjusts the clearness of the image.
