Connecting LAN (HP LD4210 and HP LD4710 only)

The LAN input on the display can connect to a media player/computer, a router (switch), or an

Intranet. A LAN connection with the display establishes communication between your media player/

computer and the display. This enables the use of the HP Network Sign Manager program, running on

the connected media player/computer, to assign an IP address to the display, to change display

settings, and to set up HP Media Sign Player options, play lists, and On/Off schedule times.

1.

Connect the LAN cable (not included) using one of the following connections:

Computer Direct Connection—Connect the LAN cable to the LAN port on the display and to

the LAN port on the media player/computer (1).

Router—Connect the LAN cable to the LAN port on the display and to a LAN port on the

router (2).

Intranet—Connect the LAN cable to the LAN port on the display and to the Intranet network

via an access point (3).

Figure 3-31

Connecting the LAN cable

1

2

3

2.

Install the HP Network Sign Manager on the media player/computer attached to the Intranet. To

download the HP Network Sign Manager, refer to the website

www.hp.com

. For details on using

the HP Network Sign Manager application, refer to the HP Network Sign Manager User Guide

(available only in English) included on the CD provided with the display.
