28
4 Basic Operations
3
Have the patient stare at the internal eye fixation lamp to fix the part for the photograph.
Take the following steps to guide the patient’s eye: Press the FIX TARGET buttons up, down, left, and
right to move the internal eye fixation lamp to your desired position and then press the set button
to make it blink. If the eye cannot be guided by the internal eye fixation lamp, use the external eye
fixation lamp (sold separately).
Set button
Press the set button for at least two seconds to reset the position of the internal eye fixation lamp.
See the Rics NM 2 manual for details.
4
Perform a preliminary check before taking photos.
a. The photography ready lamp lights green.
b. The working distance dots appear.
c. The focus indicator appears.
ON ON
㻭㻲
a
b
c
Photography ready lamp
t Green: Ready to shoot.
t Red: Preparing to shoot. Wait until the lamp lights green.
Flash intensity adjustment
The flash intensity is set JOBEWBODFto the standard level.
Every time the flash intensity button is pressed the flash
intensity increases by 0.3 stop.
Appearance of flare
Even if the working distance dots are adjusted to be extremely clear, flare may appear around the
retinal image depending on the patient’s eye.
