4.2.2. Media width and length
The media width and length is described in millimeters. 0 to 255 (FF Hex)
The width of continuous length tape is indicated in millimeters of the tape width, and the width of
die-cut labels is indicated by the width of the die-cut section.
The length of continuous length tape is fixed to “00 Hex”, and the length of die-cut labels is
indicated by the length of the die-cut section.
Continuous length tape
Media Media Width Media Length
12mm 12 0
29mm 29 0
38mm 38 0
50mm 50 0
54mm 54 0
62mm 62 0
102mm 102 0
Die-cut labels
Media Media Width Media Length
17 mm x 54 mm 17 54
17 mm x 87 mm 17 87
23 mm x 23mm 23 23
29 mm x 90 mm 29 90
38 mm x 90 mm 38 90
39 mm x 48 mm 39 48
52 mm x 29 mm 52 29
62 mm x 29 mm 62 29
62 mm x 100 mm 62 100
102mm x 51mm 102 51
102mm x 152mm 102 153
12 mm Dia 12 12
24 mm Dia 24 24
58 mm Dia 58 58
Brother QL-500/550/560/570/580N/650TD/700/1050/1060N Command Reference
15
