QL-1050/1060N: Total number of pins 1296 pins
Continuous length tape:
Label Size Number of
Pins for Left
Margin
Number of Print Area
Pins
Number of
Pins for Right
Margin
Number of Raster
Graphics Transfer
Bytes
12mm 1116 106 74 162
29mm 940 306 50 162
38mm 827 413 56 162
50mm 686 554 56 162
54mm 662 590 44 162
62mm 544 696 56 162
102mm 76 1164 56 162
Die-cut labels:
Label Size Number of
Pins for Left
Margin
Number of Print Area
Pins
Number of
Pins for Right
Margin
Number of Raster
Graphics Transfer
Bytes
17mm x 54mm 1087 165 44 162
17mm x 87mm 1087 165 44 162
23mm x 23mm 976 236 84 162
29mm x 90mm 940 306 50 162
38mm x 90mm 827 413 56 162
39mm x 48mm 821 425 50 162
52mm x 29mm 674 578 44 162
62mm x 29mm 544 696 56 162
62mm x 100mm 544 696 56 162
102mm x 51mm 76 1164 56 162
102mm x 152mm 76 1164 56 162
12mm Dia 1046 94 156 162
24mm Dia 975 236 85 162
58mm Dia 584 618 94 162
Brother QL-500/550/560/570/580N/650TD/700/1050/1060N Command Reference
11
