4.Status
4.1. Overview
The status is sent from the printer to the computer as a reply to the “status information request”
command or as an error message. The size is fixed to 32 bytes.
Number Offset Size Name Value/Reference
1 0 1 Print head mark Fixed to “80 Hex”
2 1 1 Size Fixed to “20 Hex”
3 2 1 Reserved Fixed to ’B’ (42 Hex)
4 3 1 Reserved QL-500/550/650TD/1050:
Fixed to ’0’ (30 Hex)
QL-560/570/580N/700/1060N:
Fixed to ’4’ (34 Hex)
5 4 1 Reserved QL-500/550: Fixed to ‘O’ (4F Hex)
QL-560: Fixed to ‘1’ (31 Hex)
QL-570: Fixed to ‘2’ (32 Hex)
QL-580N: Fixed to ‘3’ (33 Hex)
QL-650TD: Fixed to ‘Q’ (51 Hex)
QL-700: Fixed to ‘5’ (35 Hex)
QL-1050: Fixed to ‘P’ (50 Hex)
QL-1060N: Fixed to ‘4’ (34 Hex)
6 5 1 Reserved Fixed to ’0’ (30 Hex)
7 6 1 Reserved Fixed to “00 Hex”
8 7 1 Reserved Fixed to “00 Hex”
9 8 1 Error information 1 Refer to section 4.2.1.
10 9 1 Error information 2 Refer to section 4.2.1.
11 10 1 Media width Refer to section 4.2.2.
12 11 1 Media type Refer to section 4.2.3.
13 12 1 Reserved Fixed to “00 Hex”
14 13 1 Reserved Fixed to “00 Hex”
15 14 1 Reserved Not set
16 15 1 Reserved Not set
17 16 1 Reserved Fixed to “00 Hex”
18 17 1 Media length
Refer to section 4.2.2.
19 18 1 Status type Refer to section 4.2.4.
20 19 1 Phase type Refer to section 4.2.5.
21 20 1 Higher order bytes of
phase number
Refer to section 4.2.5.
22 21 1 Lower order bytes of Refer to section 4.2.5.
Brother QL-500/550/560/570/580N/650TD/700/1050/1060N Command Reference
12
