3.2.3. Feed amount
The feed amount (left and right margins) is defined below.
Tape Type Minimum Margin Setting Maximum Margin Setting
Continuous
length tape
mm setting: 3 mm
Inch setting: 0.1”
35 dots
mm setting: 127 mm
Inch setting: 5”
1500 dots
Die-cut labels Set the command for specifying the margin to “0”.
In case of using 12 mm Dia for QL-500/550/560/570/580N/700, specify 35
dots.
3.2.4. Maximum and minimum lengths
The maximum and minimum lengths are defined below.
Tape Type Minimum Length Maximum Length
Continuous length tape (QL-500/550/560/650TD/1050
/1060N)
25 mm
295 dots
(QL-570/580N/700)
12.7 mm
150 dots
(QL-500/550/560/570/580N/65
0TD/700)
1000 mm
11811 dots
(QL-1050/1060N)
3000 mm
35433 dots
Die-cut labels Fixed Fixed
Brother QL-500/550/560/570/580N/650TD/700/1050/1060N Command Reference
9
