Page 18

Royal Series Water Temperature Control Units

Ferrous piping is recommended to minimize galvanic action. If
piping must be copper, use dielectric unions at the unit.


3-5 Piping Considerations for High Mobility

Installations

Mobile Royal Series systems must use high quality hose rated for
at least 150 psig and 250

°F (1,034.25 kPa/10.34 bars and 121ºC).

Special 300

°F (149ºC) high temperature Royal Series systems

must use hosing rated at 150 psig and 300

°F (1,034.25 kPa/10.34

bars and 149ºC) or greater.

Quick disconnects may be used for mobility, although they cause
a drop in pressure
. If used, they must be sized carefully to
minimize pressure drop. Don’t use quick disconnects with check
valves unless absolutely necessary.

!

CAUTION

Non-relieving quick connect fittings or check valves on the water supply

must have a pressure relief piped to the drain.

Failure to do so could result in a dangerous over-pressure condition!


3-6 Process Water Considerations

Raw Water

Water treatment is vital in any piping system. In some cases, raw
water may be used in the system without problems; in other cases,
it can result in large deposits of scale and corrosion.

Sterling offers a complete line of water treatment equipment.
Contact your Sterling sales representative for water testing and
treatment options.


Distilled Water

Non-ferrous (brass, copper, or high-temperature plastic) piping is
recommended for distilled water processes.
