Sterlco SGBD Series Batch Gravimetric Blenders - Manual (Page 92)

BLN1-600 Chapter 7: Appendix 92 of 110
7-3 Spare Parts Kits *
Figure 66: Blender Spare Parts Listing
Model 150 500 900 2500 4000 6000
KIT "A" (Consumables) A0574120 A0574134 A0574137 A0574125 A0574140 A0574143
Load Cell Assembly (without plug) # 724.00767.00 724.00768.00 724.00770.00 724.00771.00 724.00772.00
Mixer High Level Sensor #
KIT "B" (Minimal Downtime) A0574121 A0574135 A0574138 A0574126 A0574141 A0574144
All "A" Kit Parts A0574120 A0574134 A0574137 A0574125 A0574140 A0574143
Slide Gate Air Cylinder - Majors #
Slide Gate Air Cylinder - Minors # 35448
Weigh Hopper Air Cylinder #
Mixer Motor Contactor
Power Supply, 24vdc
Mixer Door Safety Switch
#
Circuit Breaker (2 amp) x 2
Circuit Breaker (3 amp) x 2
KIT "C" (24/7 Operation, or International) A0574122 A0574136 A0574139 A0574127 A0574142 A0574145
All "A" and "B" Kit Parts A0574121 A0574135 A0574138 A0574126 A0574141 A0574144
Second Load Cell Assembly (without plug) 724.00767.00 724.00768.00 724.00770.00 724.00771.00 724.00772.00
Mixer Motor Protector (overload)
Calex Module
Other Recommended Parts 150 500 900 2500 4000 6000
Mixer Gear Motor # 720.00002.00
Reducer
Right Angle Reducer
Mixer Agitator # 872.00101.00 872.00102.00 872.00225.00
Mixer Coupling N/A 832.00030.00
Weigh Hopper Assembly # A0771684 A0771685 A0771662 A0771704 A0771705
Valve Stack Assembly N/A
A-B PanelView Operator Touch Screen
(no enclosure)
A-B PLC MicroLogix CPU
245.00006.00 245.00016.00
891.00021.00
A0556548
35448 245.00016.00
245.00003.00 A0770248
A0558252 A0558255
729.00202.02
727.00207.00
727.00208.00
A0563932
717.00078.00
724.00117.00
720.00001.00 51354
872.00228.00
891.00024.00
832.00010.00
A0770132 (4-Component) -or- A0770144 (6-Component)
N/A
160.00280.00
51415
832.00181.00
* Parts list for current blender software (Rev 4.X or higher). Consult factory for Pre 4.X software blender.
