Menu Structure for Batch Blenders
Recipe Page—Start
Ø Change Recipe Values by
touching the number you
wish to change
Ø Touch “Accept New Recipe”
button after you’ve made the
desired changes
Ø Touch “Undo” button to
cancel a recipe change
before accepting it
Ø Start or stop the blender by
touching the “Push to Start or
Stop” button
Ø Access “Recipe Book ” Page
Ø Access “Clean Out” Page
Ø Access “Inventory” Page”
Ø Access “Setup” Page
“Recipe Book” Page
Save the running recipe to the
book.
• Delete a stored recipe
• Load a stored recipe
• Erase all stored recipes
• Modify the product ID for a
stored recipe
• Return to the Recipe Page
“Clean Out” Page
• Empty the blender hoppers
• Manually operate mixer,
weigh hopper dump gate,,
and slide gate below mixer
• View/test all inputs/outputs
on the blender
• Return to Recipe Page
“Inventory” Page
• View/print accumulated
inventories
• View batch time
• View maximum capacity
• View average process rate
• Return to Recipe Page
“Setup” Page
• Touch the “ACS” icon and
enter in user password
Recipe Format
• Percentage, Parts, or
EZ mode
• Metering order
• Batch size
• Inventory shutdown
• “Batch ready” mode
• “Auto start” mode
• Weigh every batch
options
• Change recipe
without stopping
•
Report Setup
• Blender number
• “Auto print” option
• “Auto clear” option
• “Auto interval” option
• Auto start time
Calibration
• Scale Calibration
• Direct Scale Readout
• Feeder Calibration
Mixer & Dump Setup
• Mixing time
• Remix time
• Dump time
• Dump delay
• Dump cycles
• Mixer dump time
• Time/continuous mixing
option
Panel View “Config”
• View software version
• Access Panel View “Config”
setup to modify printer/time
settings and to load new
software
User Password
• Change default user password
Units
• Blender data units (lbs/kg)
• Target v. actual data units
(lbs/kg)
Alarm Log
• View, print, or clear alarm log
Alarm Setup
• “Stop/Continue” when
out of material
• “Alarm/No Alarm” when
out of material
• “Alarm Silence” delay
• Accept recipe alarm
enable/disable
• Missing ingredient
Network Setup
• IP Address
• Subnet Mask
• Send Config to ENI
Module
• Enable Ethernet
Configurator
• Modbus Plus Disabled
•
User Interface Lock
• Lock the user interface to
prevent others from making
changes or viewing the blender
