1 2 3 4 5 6 7 8 Standard temperature output ranges
9 X -50…200 °F
S T Custom range. Specify when ordering
P P 3 Pt 100 1/3 class B, 4-wire direct connection
P P 5 Pt 100 1/5 class B, 4-wire direct connection
P P A Pt 100 1/10 class B, 4-wire direct connection
Optional keypad and display
D Keypad and display with backlight
X No keypad and display
Probe length options (except wall mount configuration)
S Standard length
1 Standard length + 150 mm
2 Standard length + 300 mm
3 Standard length + 450 mm
4 Standard length +600 mm
Cable fittings
1 1x M16 cable grip (85 to 265 VAC: 2 cable grips)
3 1x ½” conduit adapter (85 to 265 VAC: 2 conduit adapters)
Standard dew / frost point output ranges
X X No calculated parameter
B X -50…50 (°C / °F - as per temperature output range)
C X -50…100 (°C / °F - as per temperature output range)
D X -50…200 (°C / °F - as per temperature output range)
S C Custom range. Specify when ordering
Notes:
o
Output 1: relative humidity or dew point
o
Output 2: temperature
o
The enclosure of all HF6 models is designed to be installed in the horizontal position
o Cable grips are located at the bottom of the enclosure (models with 85 to 264 VAC supply voltage have 2
cable grips)
o
Conduit adapters are located on top of the enclosure (models with 85 to 264 VAC supply voltage have 2
conduit adapters)
o
The dew / frost point range uses the same unit (˚C or ˚F) as the temperature output. The factory default
setting is frost point below freezing.
o
Custom range: be sure to clearly specify the desired range at the time of the order. When a special range
has been ordered, the letters ST and SC are used in columns 4 and 7 in the above table. These generic
codes will be replaced with a specific code only for quantity and repeat orders
