E-M-HF63_65-V1_11
Rotronic AG
Bassersdorf, Switzerland
Document code Unit
Instruction Manual
Document Type
HygroFlex HF63/HF65 Humidity Temperature
Transmitters: User Guide
Document title
Page 24 of 34
© 2008; Rotronic AG E-M-HF63_65-V1_11
Main Menu
Menu Items Selections / Information Notes
Device Information
Version Firmware version
Serial Nbr Serial number
Address RS-485 address
Type Device type
Name Device name User defined
SensorTest Humidity sensor status Off / Good / SQ-Tuned / Bad
Humidity Adjust
RefValue Humidity reference value ± 0.1 %RH steps
1-point adjustment only (offset)
Temperature Adjust
RefValue Temperature reference value ± 0.1 ˚C steps
1-point adjustment only (offset)
o
Record: both the recording mode (start / stop and the log interval cannot be changed from the menu and
are as configured with the ROTRONIC HW4 software
o
SensorTest: Off means that the humidity sensor has not been tested due to the configuration settings of
the test. For a description of the automatic humidity sensor test and drift compensation (SQ-tuning) see
documents E-T-AC3000-DF-V1 and E-M-HW4v2-F2-008
7.5 Displayed parameters (optional keypad and display)
When the menu is not active, press the ENTER key to change which parameters are shown on the display:
o
Relative humidity and temperature
o Dew / frost point and temperature (when the calculated parameter is enabled)
8 Maintenance
8.1 Service cable
• Cable AC3006 is used to connect the HF63 or HF65 to a USB port of a PC running the ROTRONIC HW4
software.
• As an alternative, cable AC2001 is used to connect the HF63 or HF65 to a probe input of the HP23 hand-
held calibrator. For service purposes, the HP23 offers essentially the same functionality as the HW4
software.
