11.3 Mounting hardware
Order Code Description
AC5002
DIN-rail mounting kit consisting of 2 clamps
that attach to the back of the enclosure with
the screws provided.
DIN-rail (35 mm / 1 3/8”) not included
QMA-15
Consists of mounting flange (AC1305) and
compression fitting (AC1303-M) for 15 mm /
0.6” diameter probe.
Use for though wall installation of the HF6
type D
Maximum temperature 200 °C (392°F)
11.4 Calibration accessories
Order Code Description
EA00-SCS 0.5 %RH humidity std, SCS cert., pack of 5
EA05-SCS 5 %RH humidity std, SCS cert., pack of 5
EA10-SCS 10 %RH humidity std, SCS cert., pack of 5
EA20-SCS 20 %RH humidity std, SCS cert., pack of 5
EA35-SCS 35 %RH humidity std, SCS cert., pack of 5
EA50-SCS 50 %RH humidity std, SCS cert., pack of 5
EA65-SCS 65 %RH humidity std, SCS cert., pack of 5
EA80-SCS 80 %RH humidity std, SCS cert., pack of 5
EA95-SCS 95 %RH humidity std, SCS cert., pack of 5
ER-15 Calibration device for 15mm diameter probes
For instructions regarding the ROTRONIC humidity standards and calibration devices see document
E-M-CalBasics.
11.5 Dust filters for wall mount models
Order Code Slotted cap Filter insert
NSP-PCB-PE Polyethylene
NSP-PCB-WM Wire mesh
NSP-PCB-TF
Polycarbonate, black
Teflon
