8: Specification
51
ELECTRICAL
Supply Voltage:
Mains Input Voltage:
86 to 264 Vac.
Mains Input Frequency:
47 to 63 Hz.
Power Consumption:
10.5 W.
Alternative Input Supply:
24 V(ac/dc), 1 A max. (The 24 Vac supply must be isolated from earth.)
MECHANICAL
Enclosure:
Material:
ABS and aluminium.
Dimensions:
9 x 7 x 4.7 inches.
Weight:
2.65 lb.
Protection:
IP65.
Fixing:
Wall mountable.
Keypad:
No. Keys:
15 key tactile feedback membrane keypad.
Display:
Format:
240 x 64 pixel graphic display, high contrast black-on-white, with backlight.
Viewing Angle:
Min 30°, typically 40°.
Active Area:
5.0 in (W) x 1.3 in (H).
Overlay:
Standard English, Optional overlays available.
ENVIRONMENTAL
Operating Temperature:
-4°F to +122°F (-20°C to +50°C).
Storage Temperature:
-13°F to +167°F (-25° to +75°C).
Operating Humidity:
90% RH MAX at +122°F.
APPROVALS
Safety:
BS EN 61010-1:2001.
EMC:
BS EN 61326 - 1:2006, BS EN 61326-2-3:2006.
Environmental:
BS EN 60068-1:1995, BS EN 60068-2-1:2007, BS EN 60068-2-2:2007.
