Page 42: Paragraph 4.2, Data logging
4: Data Logging
38
4.2
How to Set Up Automatic (Timed) Logging Mode
This procedure shows you how to set up an auto logging session under timed start/stop control. The logged data
is saved to the instrument’s memory and can be downloaded at a later time.
Starting point
This procedure assumes that the instrument has been correctly installed and is operating in the
FLOW READING
mode. Also, that the instrument’s date and time are set correctly.
Setting up, starting and cancelling auto logging
1.
With the UFC instrument operating in
FLOW READING mode, check that the indicated flow units are the same
as those you want to appear on the logger output (e.g.
l/min).
2.
Press the
Logger function key to access the
REAL TIME LOGGER screen.
3.
Select
Logging interval and enter the
required period (e.g.
10 seconds).
4.
Select
Start date & time and enter the
date and time you wish logging to commence.
Note this must be in the future.
5.
Select
Stop date & time and enter the date
and time you wish logging to cease. Note this
must be later than the start time.
6.
Select
Set Auto start. This enables the
auto logging application.
If
Set Auto start is enabled with valid start
and stop times, this entry will change to
Cancel Auto start.
7.
To cancel the automatic logging session before
it commences, click
Cancel Auto Start.
8.
Select
Exit to return to the FLOW READING
screen.
Key Point: When entering the Start and Stop times in this procedure, you must
enter ‘00’ in the seconds field rather than leave it blank, otherwise an error message
is displayed.
REAL TIME LOGGER
Logging to SD card
Unit : l/min
Log name : Quickstart
Log data to : USB
Logging interval : 10 seconds
Start date & time : dd-mm-yy hh:mm:ss
Stop date & time : dd-mm-yy hh:mm:ss
View log as text
START NOW
Set Auto start
Clear log
Exit
REAL TIME LOGGER
Logging to SD card
Unit : l/min
Log name : Quickstart
Log data to : USB
Logging interval : 10 seconds
Start date & time : dd-mm-yy hh:mm:ss
Stop date & time : dd-mm-yy hh:mm:ss
View log as text
START NOW
Set Auto start
Clear log
Exit
