3: Operating Procedures
18
3.1.2 Changing the user language
If you want to change the user language at any time
after the instrument has been put into operation:
1. Select Setup Instrument from the MAIN
MENU then press ENTER.
2. Select Change Language from the SETUP
INSTRUMENT screen then press ENTER.
3. Select the required language from the list
provided and press
ENTER.
4. The instrument returns to the MAIN MENU.
3.1.3 Changing the date and time
The correct date and time should have been set
when the instrument was initially put into service. To
update the date/time parameters:
1. Set the required Date & Time as described in
Paragraph 3.1.1.
3.2 Using the Quick Start Menu
The Quick Start menu gathers various data for the site to be monitored and returns details of the transducer
configuration that must be applied when mounting the transducers on the pipe.
Before you can use the UFC system you need to obtain the following details (this information is required when
setting up the
Quick Start menu):
• The pipe outside diameter.
• The pipe wall thickness and material.
• The pipe lining thickness and material (if any).
• The type of fluid contained in the pipe being monitored.
• The fluid temperature.
Entering the site data
1. Select Quick Start from the MAIN MENU and press ENTER. You will then be presented with a series of
screens in which to enter the data mentioned above.
2. Select the dimension units (millimeters or
inches) used to measure the pipe, then press
ENTER.
SETUP INSTRUMENT DD-MM-YY HH:MM:SS
Set Date & Time : dd-mm-yy hh:mm:ss
Calibrate 4-20mA
Factory settings
Change Language
Exit
SETUP INSTRUMENT DD-MM-YY HH:MM:SS
Set Date & Time : dd-mm-yy hh:mm:ss
Calibrate 4-20mA
Factory settings
Change Language
Exit
DIMENSION UNIT DD-MM-YY HH:MM:SS
Select the dimension units:
mm
➥ Inches
