3: Operating Procedures
20
8. If a lining thickness value was entered earlier,
this screen is displayed to request that you
enter the lining material type. If no lining
thickness was entered this screen will be
bypassed.
9. Select the lining material from the list provided
then press
ENTER.
If the material is not listed select Other and
enter the propagation rate of the lining material
in meters/sec. Contact Dwyer if this is not
known
10. Select the fluid type from the list provided and
press ENTER.
If the liquid is not listed select Other and enter
a propagation rate in meters/second.Contact
Dwyer if this is not known
11. If you need to alter the fluid temperature from
that shown select either °C or °F with the
cursor and press the ENTER key.
12. Enter the new temperature value and press the
ENTER key.
13. The new temperature should now be indicated
in both °C and °F.
14. Select Continue.. and press ENTER.
15. The SENSOR SEPARATION screen now
displays a summary of the entered parameters
and informs you of the type of sensor to be
used, the mode of operation, and the distance
to set up between the sensors.
In this example, it recommends type
A-ST (A
standard) sensors operating in the ‘ Reflex’
mode spaced at 3.62 Inches apart.
Take a note of these details.
Key Point: The above example shows the spacing required using a standard type
‘A’ probe set (A-ST), as supplied with the model UFC-A.
PIPE LINING MATERIAL DD-MM-YY HH:MM:SS
Select pipe lining material
Steel
Rubber
Glass
Epoxy
Concrete
Other (m/s)
FLUID TYPE DD-MM-YY HH:MM:SS
Select fluid type
Water
Glycol/water 50%
Glycol/water 30%
Lubricating oil
Diesel
Freon
Other (m/s) ––
FLUID TEMPERATURE DD-MM-YY HH:MM:SS
Enter Fluid Temperature
°C: 5.00
°F: 41.00
Continue..
SENSOR SEPARATION DD-MM-YY HH:MM:SS
Site : Quickstart
Pipe : 6.50 Inches
Wall : 0.50 Inches
Sensors : A-ST Reflex
Temperature : 5.00°C 41.00°F
Set sensor separation to 3.62 Inches
Press
to continue, UV to select sens.
