3: Operating Procedures
19
3. Enter the pipe outside diameter dimension,
then press
ENTER.
4. Enter the pipe wall thickness dimension, then
press
ENTER.
5. If the pipe has a lining, enter the lining
thickness.
If nothing is entered the instrument
automatically assumes there is no lining.
6. Press ENTER to continue.
7. Select the pipe wall material from the list
provided, then press
ENTER.
If the material is not listed select Other and
enter the propagation rate of the pipe wall
material in meters/sec. Contact Dwyer if this is
not known.
OUTSIDE DIAMETER DD-MM-YY HH:MM:SS
Dimensions: Inches
Pipe outside diameter: 6.50
PIPE WALL THICKNESS DD-MM-YY HH:MM:SS
Dimensions: Inches
Pipe outside diameter: 6.50
Pipe wall thickness: 0.50
PIPE LINING THICKNESS DD-MM-YY HH:MM:SS
Dimensions: Inches
Pipe outside diameter: 6.50
Pipe wall thickness: 0.50
Pipe lining thickness: 0.12
PIPE WALL MATERIAL DD-MM-YY HH:MM:SS
Select pipe wall material
Mild Steel
S' less Steel 316
S' less Steel 303
Plastic
Cast Iron
Ductile Iron
Copper
Brass
Concrete
Glass
Other (m/s)
