2.0 Specifications
2.1 Materials of construction
Wetted components: Non-Wetted components:
Enclosure:
413 Aluminum (Polyester powder coated)
Pump Head:
q Valox (PBT) thermoplastic
Pump Head Cover:
Clear Acrylic - Annealed for added strength and chemical
resistance.
Permanently lubricated sealed motor shaft support ball bearing.
Acrylic shaft support bearing retainer.
Cover Screws:
Stainless Steel
Roller Assembly:
q Rotor: ..................................Valox (PBT)
Rollers: ...............................Nylon
Roller Bearings: .................SS Ball Bearings
Motor Shaft:
Chrome plated steel
TFD System Sensor pins:
Hastelloy C-276
Power Cord:
3 conductor, SJTW-A Water-resistant
Tube Installation Tool:
GF Nylon
Mounting Brackets and Hardware:
316 Stainless Steel
Power Cord Options:
115V60Hz = NEMA 5/15 (USA)
230V60Hz = NEMA 6/15 (USA)
220V50Hz = CEE 7/VII (EU)
240V50Hz = AS 3112 (Australia/New Zealand)
Motor:
Brushed DC, 1/8 H.P.
Duty cycle:
Continuous
Motor speed adjustment range 100:1:
1.0% - 100% motor speed (1.3 to 130 RPM)
Motor speed adjustment resolution:
0.1% increments
Display
Backlit LCD, UV resistant.
Keypad
Eight button positive action tactile switch keypad.
Enclosure:
NEMA 4X (IP66), Polyester powder coated aluminum.
Maximum Overall Dimensions:
7-1/2” W x 10-1/4” H x 14” D (19 W x 26 H x 35.6 D cm)
Approximate shipping wt:
25 lb. (12.0 Kg)
Maximum working pressure (excluding pump tubes) :
125 psig (8.6 bar)
Note: see individual pump tube assembly maximum pressure
ratings.
Maximum Fluid temperature (excluding pump tubes) :
o o 3/8” OD x 1/4” ID tubing connections: 130 F (54 C)
o o M/NPT connections: 185 F (85 C)
Note: see individual pump tube assembly maximum temperature
ratings.
Maximum fluid viscosity:
12,000 Centipoise
Maximum suction lift:
30 ft. Water, 0 psig (4.5 m, 0 bar)
Ambient Operating Temperature
O O O O 14 F to 115 F (-10 C to 46 C)
Ambient Storage Temperature
O O O O -40 F to 158 F (-40 C to 70 C)
Operating Voltage:
115VAC/60Hz, 1ph (1.5 Amp Maximum)
230VAC/60Hz, 1ph (0.7 Amp Maximum)
220VAC/50Hz, 1ph (1.0 Amp Maximum)
240VAC/50Hz, 1ph (1.0 Amp Maximum)
Pump Tube Assembly (Model Specific - 2 provided) :
q q q Tubing: . . . . . Norprene or Norprene Chemical or Tygothane
Adapter fittings: .PVDF
Injection / Back-flow Check valve:
Body & insert: ....................PVDF
Check Ball: .........................Ceramic
Spring: ................................Hastelloy C-276
q Ball Seat O-ring:.................Viton (optional EPDM)
q Static Seal O-ring: ..............Viton (optional EPDM)
q Duckbill anti-scale valve: Santoprene
Ancillary Items provided
With “S” tubing type connections only:
Suction Tubing: . . . . . 3/8” OD x 1/4” ID x 10’ Clear PVC
Discharge Tubing: . . . . 3/8” OD x 1/4” ID x 10’
Polyethylene
(LLDPE)
Suction Strainer: . . . . . Polypropylene
Suction Strainer:
Body:. . . . . . . . . . . PVDF
Check Ball: . . . . . . . . Ceramic
q Ball Seat O-ring: . . . . . Viton (optional EPDM)
With “B” tubing and “M” M/NPT connections only:
Suction Strainer:
Body: . . . . . . . . . . . . . . . . . PVDF
Check Ball: . . . . . . . . . . . . Ceramic
q Ball Seat O-ring: . . . . . . . . Viton (optional EPDM)
With “C” Tri-clamp connections only:
none
