Page 24 Flex-Pro
Used to remotely control pump with an incoming pulse signal. Can be used with an external foot pedal, a water
meter, a PLC, contact closure, or other low speed pulse devices.
Default setting: 1 Pulse = 100% motor speed for 2.5 seconds
Time-out - Flex-Pro pumps have a time-out setting of 20 seconds while in configuration menus. If built-in timer exceeds 20 seconds
without a button being pressed, then pump will exit configuration menu. Changes will only be saved after RIGHT arrow button is
pressed and released.
Step 1
Press and release STOP button
Note: Mode cannot be changed while pump is in running.
Press and release SELECT RUN MODE button multiple
times until Mode 2 is selected.
Step 2
With Mode 2 selected, press and hold SELECT RUN MODE
button until ‘On’ icon begins flashing.
This indicates that you’ve entered Setup menu.
Step 3
Pump on-time will be displayed in either MIN (minutes) or
SEC (seconds).
To increase value, press and release UP arrow.
To decrease value, press and release DOWN arrow.
To save value, press and release RIGHT arrow.
Default Setting
Mode 4
100.0
Mode 4
OFF
MIN
4
4
Step 4
MIN (minutes) or SEC (seconds) will be displayed in lower
right hand corner. This value will be linked to Pump on-time
number in previous screen.
To change this setting, press and release either UP arrow or
DOWN arrow.
To save value, press and release RIGHT arrow.
Mode 4
Mode 4
0 200 400 600 800 1000
0
25
50
75
100
Pump Motor Speed (%)
Frequency Input (Hz)
0%
Output
100%
Output
Hz
ON
ON
Hz
100.0
MIN
4
ON
Hz
4
ON
Hz
SEC
11.0 Mode 4 - Pulse Batch (low speed pulse) Operation
MIN or
SEC
