Mode 0 - Setup
Press and Hold to configure:
Ÿ Remote Start / Stop
Ÿ TFD (Tube Failure Detection) sensitivity
Ÿ FVS (Flow Verification Sensor) time delay - requires sensor
Ÿ 4-20 mA output, available on certain models
Mode 0
Mode 1 - Manual
Run pump locally by selecting pump speed (1 - 100%).
Ÿ Control speed by using up or down arrows after start button is
pressed.
Ÿ Control speed by entering Mode 1 setup and selecting desired
pump speed (1 - 100%)
Mode 2 - 4-20 mA Input Signal
Run pump remotely via external 4-20 mA signal.
Ÿ Press and Hold “Select Run Mode” button with Mode 2
selected to configure settings.
Ÿ Select Mode 2 and press START button to allow pump to be
controlled by external 4-20mA signal.
Mode 3 - Frequency (Hz) Input Signal
Run pump remotely via external high frequency (Hz) signal.
Ÿ Press and Hold “Select Run Mode” button with Mode 3
selected to configure settings.
Ÿ Select Mode 3 and press START button to allow pump to be
controlled by external frequency (Hz) signal.
Mode 4 - Pulse Batch Input Signal (low speed pulse)
Run pump remotely via external low speed pulse signal.
Ÿ Press and Hold “Select Run Mode” button with Mode 4
selected to configure settings.
Ÿ Select Mode 4 and press START button to allow pump to be
controlled by external low speed pulse signal.
SEt
0
Mode 1
OFF
1
Mode 2
OFF
2
Mode 3
OFF
3
Mode 4
OFF
4
Page 11 Flex-Pro
SPEED
mA
Hz
Hz
ON
6.1 Mode Descriptions
