MC4Con SoFTWAre
Data Table Controls
The peak pressure and current data tables use the same controls for manipulating the available data
Save TXT Stores the table in a * txt
Excel open Stores the table in Microsoft Excel * xls format
Copy Copies the current file
Delete Deletes the current file
Open TXT Opens a previously stored file
Graph Generates a graphics representation of the current table
Cancel Exits from the current data table
Print Prints the current table The graphic view prints after the table is converted into graphic
Format
US Uses a decimal point as number separator
EU Uses a comma as number separator
Peak Pressure P1 - Data Table
Peak Pressure P1 Peak Pressure P1
Save TXT
Excel open
Copy
Delete
Open TXT
Graph
Cancel
Print
Format
EU US
12 Lines
ms Tr. (bar) +1 +2 +3 +4 +5 +6 +7 +8 +9
Date
Time
Interval
10
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
190
200
210
220
230
240
250
260
270
280
290 23.07.2013
08:47:59
1000
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135 9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135 9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135 9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135 9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135 9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135 9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135 9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135 9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
9,90135
Figure 12: Peak pressure table
