MC4Con SoFTWAre
Pressure Pressure parameter settings.
Scale P1 Full scale for the first pressure sensor (P1)
Scale P2 Full scale for the optional pressure sensor (P2)
Save Interval Sampling and recording rate during data collection
Threshold
The threshold signal level for the P1 (Transient) Defines the point at which transient
recording starts
RPM RPM parameter settings.
Scale rpm Multiplication constant for rpm scaling
DScale rpm Division constant for rpm scaling
New-Tab Three point linearizing of flow sensors.
example
Tab F1 INP First frequency point 0 Hz Tab Q1 OUT First displayed flow reading 0 LPM
Tab F2 INP Second frequency point 166 Hz Tab Q2 OUT Second displayed flow reading 38 LPM
Tab F3 INP Third frequency point 630 Hz Tab Q3 OUT Third displayed flow reading 150 LPM
Units Flow units are calculated in US or European standard units.
EU Default units are lpm, bar, ° C
US Default units are gpm, psi, ° F
Language Selection of English or default (the local country language).
English
Default
Backlight Backlight control.
Light off Backlight is turned off No instrument backlight
Light on Backlight is turned on The display illuminates for 30 seconds when any buttons are pressed
File Menu MC4000, upper tree switches.
New Device Default setting
File Read Reads all the menu parameters from a file with the file format filename set from the MC4000
File Save Stores all the menu parameters in a file with the format filename set to the MC4000
Device Menu MC4000, lower three switches.
Menu MC4000 read Reads the stored MC4000 parameters into the MC4CON software
Menu MC4000 store Reads the stored MC4CON parameters into the MC4000
Timer MC4000 write Transfer time and date values from the PC into MC4000
