oPerATIon
New Datalogging Session
DATALOGGER
STORE ON
To start the next datalogging session select
dATAloGGer STore on
again and confirm the selection by pressing OK
Recording Interval
The save interval is the time between two consecutive recording cycles It is set in fixed increments as shown below
SAVE INTERVAL
1 s
Selection 1s, 2s, 5s, 15s, 30s, 60s, 120s, 300s, 600s,
1200s, 1800s, 2700s, 3600s, 7200s
Fast Transients - Pressure Channel P1
For recording of fast transients two memory locations are available Each location is individually selected Each transient
contains a maximum 240,000 samples For example with a sampling rate of 1 ms the memory capacity is 240 seconds in each
memory location The recording begins when OK is pressed To stop recording, press and hold OK for at least five seconds The
minimum recording time is 30 s When data recording is stopped by pressing OK, DATA STored is automatically displayed
OTEE: N An existing transient memory record must be deleted before the new record can start
The SHoW selection displays the stored measurements as graphics The X-axis shows the elapsed recorded time, the Y-axis
shows 0…100% of the full scale pressure set in the pressure channel P1 parameter setup Any recording may be stopped by
pressing OK before reaching the end of the 240 second maximum record length
TRANSIENTS
NO. 1 DELETE
Recorded data, in the transient 1 memory location, is deleted by
pressing OK at the TrAnSIenT no. 1 deleTe prompt
TRANSIENTS
NO. 1 START
Data recording, in the Transient 1 memory location, is started by
pressing OK at the TrAnSIenT no. 1 STArT prompt
TRANSIENTS
NO. 1 SHOW
A graphic of the transient 1 data is displayed by pressing OK at
the TrAnSIenT no. 1 SHoW prompt
OTEE: N The controls for transient 2 work the same way as the controls for transient 1
