MC4Con SoFTWAre
Menu Structure
Top Level
Exit
Exit
Exits MC4CON software utility
File
Open Data Table
Opens a text file with the file format filename TX2 containing stored datalogger data
Save Data Table Stores datalogger data to a text file with the file format filename TX2
Open Transient Table Opens a text file with the file format filename TX1 containing stored transient data
Save Transient Table Stores transient data to a text file with the file format filename TX1
File Read Reads setup data stored in a file with the file format filename set
File Save Stores setup data in a file with the file format filename set
Exit Exits MC4CON software utility
COM
Select COM
Opens the COM port selection utility
Select
Measurement
Same as pressing Measurement on the MC4000 instrument
Menu MC4000 Same as pressing MENU on the MC4000 instrument
Datalogger Same as pressing datalogger on the MC4000 instrument
Current Data Table Same as pressing Current data Table on the MC4000 instrument
Peak pressure P1 Same as pressing Peak Pressure P1 on the MC4000 instrument
Info
About
Version number and contact information
Language
Change
English / Default (local language, such as Spanish)
Install new Installs new language file into the MC4000
Menu Tabs
The menu tabs immediately below the main drop downs duplicates the most frequently used item from the Select menu
Measurement Same as pressing Measurement on the MC4000 instrument
Menu MC4000 Same as pressing MENU on the MC4000 instrument
Datalogger Same as pressing datalogger on the MC4000 instrument
