ORION® Water Endpoints
ENDPOINT INSTALLATION KITS
The following kits are available for pit, vault and remote endpoint installations . Instructions for using the kits are included in
this section .
TYPE DESCRIPTION KIT PART NUMBER
PIT
Through-the-Lid Installation Kit 64394-001
Below-the-Lid with Knuckles Installation Kit 64394-003
Integrated Pit Lid Hanger Installation Kit 64394-009
VAULT Vault Installation 64394-008
REMOTE
Remote Wall Mount Box Enclosure 66009-004
IR Programming Bracket (Optional) 67625-001
Remote Installation Bracket Kit 64394-029
NOTE: N Refer to the ORION Water Endpoint Parts List, available at www.badgermeter.com for individual endpoint kit
components .
A Commercial Meter Bracket Mounting Kit (64394-023) is also available for mounting a remote endpoint to a meter . The kit
includes its own Installation Data sheet .
Page 16 June 2014
