9

FIGURE 2-1

(MIN. HORZ. SPACING)

6.156"

(156.36mm)

(MIN. VERT. SPACING)

3.600"

(91.44mm)

3/16" DIA.

12.700"

(322.58mm)

14.180"

(360.17mm)

10.000"

(254.00mm)

12.700"

(322.58mm)

Figure 2-1A

0.7"

(17.78mm)

5.24"

(133.10mm)

17.04"

(432.82mm)

EC1

EC5

EC2

EC3

EC6

EC4

14.12"

(358.65mm)

12.600"

(320.04mm)

7.747"

(196.77mm)

Figure 2-1B

2.12"
(53.85mm)

12.60"
(320.04mm)

2.044"
(58.93mm)
