71

RECORDING

Pen Type

Disposable fiber tip

Pen Color

Pen 1 - Red
Pen 2 - Green

Chart Size

12 inch

Chart Drive

Stepper motor

Chart Rotation

User configurable: 0.1 to 999 hours, in 0.1 hour increments

Chart Span

Bottom and top of span, -9999 to 9999 units

Filtering

1 to 20 scans averaging (affects display and recording)

RECORDING PERFORMANCE

Chart Recording Accuracy

0.5% of chart span reference accuracy

Resolution

0.15% of chart span

Dead Band

0.3% of chart span

Response Time

20 seconds for full scale travel

Chart Rotation Accuracy

±

0.5% of rotation time, assuming all backlash removed

OPERATOR INTERFACE

Display

Four digit, 0.56" high, red, seven segment, LED display

Resolution

TCR and RTD: 0.1 and 1 degree
mV, V and mA: 0.001, 0.01, 0.1, and 1 unit

Status Indicators

Recorders: ALRM1 and ALRM2; red LEDs
Controllers: MAN, OUT1, OUT2, ALRM; yellow, red, yellow, red LEDs

Keypad

Three keys for programming and unit operation
One or Two Auto/Man keys on controllers

Display Modes

Recorders: Process value(s)
Controllers: Process value(s) or deviation(s), with or without setpoint sequentially

ALARMS

Number

Up to two process alarms for each of two inputs

Type

Recorder: Process high or low
Controllers: Process, deviation, or band

Hysteresis

Fully adjustable, 0 to 300 units, straddles alarm point

Security

Alarm setpoint changes can be prohibited

Sensor Fault Action

Alarms work normally in “Hi” and “Lo” conditions
Alarm relays are deenergized in a “SnSr” sensor break condition

ON/OFF OUTPUTS

On/Off Outputs

Assignable to alarm or control outputs

Relays

SPDT, contacts rated 5 amps resistive at 115 VAC,
2.5 amps resistive at 230 VAC, 1/8 HP at 230 VAC (single phase),
250 VA at 115/230VAC

Solid State Relay Driver

Open collector output, can provide 40mA at 3 VDC or 20mA at 4 VDC
Short circuit current is limited to 100mA

CURRENT OUTPUTS

Drivers

Assignable to process value or setpoint retransmission or control outputs

Output Span

0 to 20mA or 4-20mA, nominal

Resolution

0.02 % of 20mA; 12 bits over a 0 to 25.6mA span

Accuracy

±

0.1% to 20mA span reference accuracy

Compliance

650 ohm load
