37
TABLE 3-3 ENABLE MODE CONFIGURATION PROCEDURE
To enter the Enable mode, press the UP and DOWN keys while in OPEr, CtrL, or oFF
modes. All the display lamps will light. After 2 seconds, the display will show Cchg and the
pen(s) will move to and remain at a point above the top graduation on the chart. Continue to
press the UP and DOWN keys, after 2 additional seconds, the display will show P dn and the
Pen(s) are driven below the bottom graduation on the chart. After 6 more seconds, the
display will show EnAb. Release the keys and the display will change to EtSt. Press and
release the DOWN key and each mode to be enabled/disabled will be displayed. With the
enable mode prompt for the desired mode displayed press the SCROLL key to verify that the
displayed mode is either on (enabled) or oFF (disabled). Press the DOWN key to turn off the
mode, press the UP key to turn on the mode or press the SCROLL key to advance the display
to the next enable mode prompt. Use the "Your Setting" column in the table to record your
settings.
A hardware jumper located on the Processor Board (See Appendix A-1, Page 62) can be
used to lock/unlock the Enable mode. When the jumper is moved to the locked position, entry
into the Enable mode is not possible until the jumper is moved to the unlocked position.
Test Mode EtSt on or oFF oFF
Calibration Mode ECAL on or oFF oFF
Program Mode EPro on or oFF on
Alarm Set Mode* EASt on or oFF on
Tune Mode** Etun on or oFF on
Manual (Stby) Mode** ESby on or oFF on
Setpoint Select mode** ESPS on or oFF on
(Optional)
Setpoint Change***
ESPC on or oFF on
* RECORDERS
** RECORDING CONTROLLERS
*** LIMITS OR RECORDING CONTROLLERS
DISPLAY AVAILABLE FACTORY YOUR
DESCRIPTION CODES SETTINGS SETTING SETTING
