23

RECORDER:
ALRM1

Red

Rcdr - Lights when Alarm 1 is on.
Limit - Lights when Limit has been exceeded.

ALRM2

Red

Lights when Alarm 2 is on.

C

Red

Lights to indicate that the process value is in terms of
degrees C (Celsius).

F

Red

Lights to indicate that the process value is in terms of
degrees F (Fahrenheit).

U

Red

Lights to indicate that the process value is in terms of
Engineering units.

-

Red

Lights to indicate a negative displayed value.

SP

Green

Indicates that the value displayed is the setpoint

(Limits only)

RECORDING CONTROLLER:
MAN

Amber

Lights when the Manual StbY mode is on.

OUT1

Red

Lights when Output 1 is on or mADC output selected.

OUT 2

Amber

Lights when Output 2 is on or mADC output selected..

ALRM

Red

Lights when either Alarm is on.

C

Red

Lights to indicate that the process value is in degrees C
(Celsius).

F

Red

Lights to indicate that the process value is in degrees F
(Fahrenheit).

U

Red

Lights to indicate that the process value is in terms of
Engineering units.

SP

Green

Indicates that the value displayed is the setpoint.

-

Red

Lights to indicate a negative displayed value.

Refer to Figure 1-2 (page 7) for the display features illustration.

3.5.2 KEYPAD CONTROLS

The keys on the keypad functions include:

SCROLL: Used to :

1. Display the enabled modes.
2. While in a mode, used to sequence the parameter codes and
values.
3. Exit some Test and Calibration functions
4. Work in conjunction with other keys:

a. With the UP key to display proportional output %
b. With the DOWN Key;

1) On power up to alter model #
2) Enter Cal/Test functions

UP: Used to:

1. Exit a mode.
2. Turn a mode On in the Enable mode
3. Increase a parameter numerical value
4. View the setpoint for Pen 1 (Press release)
5. Increase the setpoint value (Press hold)
6. Work in conjunction with other keys:

a. With the SCROLL key to display proportional output %
b. With the DOWN key;

1) Lamp test (Press release)
2) Enter the Enable mode (Press and hold for 11

seconds)

AUTO

MAN

AUTO

MAN
