69

Appendix C Order Matrix

PEN 1

1

Recorder Only

2

Recording Controller

PEN 2

0

None

1

Recorder Only

2

Recording Controller

*RELAY OUTPUTS

0

None

1

One SPST

2

Two SPST

4

Four SPST

*SSR DRIVER OUTPUTS

0

None

1

One

2

Two

4

Four

4 TO 20mA OUTPUTS

0

None

1

One

2

Two

TRANSMITTER POWER SUPPLY

0

None

1

24VDC Regulated/Isolated

PEN 1 AUXILLIARY INPUT

0

None

1

Position Proportioning

2

Remote Setpoint

PEN 2 AUXILLIARY INPUT

0

None

1

Position Proportioning

2

Remote Setpoint

DIGITAL COMMUNICATIONS

0

None

2

RS-485 Total Access

ENCLOSURE OPTION

1

Glass Window NEMA 3

2

Glass Window NEMA 4X

3

Glass Window NEMA 3
with Door Lock

4

Plastic Window NEMA 3

5

Plastic Window NEMA 4X

6

Plastic Window NEMA 3
with Door Lock

* The total quantity of SPST Relays and
SSR Drivers must be less than or equal
to four.

Note: 4-20mA inputs are accommo-
dated using the 1-5V input and a 250
ohm Shunt Resistor, P/N 64411701 or
the 10-50mA input and a 2.5 ohm
Shunt Resistor, P/N 64411702. The
250 ohm resistor is included for each
input.

8

OPTION SUFFIX

(Blank)

None

VOLTAGE

1

115VAC Input

2

115/230VAC Input
