1 Valid for ConF/ othr/ dP = 0. With dP = 1 / 2 / 3 also 0,1 / 0,01 /

0,001 is possible.

Parameter setting level

Parameters

62

8800 process controller

PAr.2

Name

Value range Description

Default

Pb12

1...9999 1

Proportional band 1 (heating) in phys. dimensions (e.g. °C),

2. parameter set

100

Pb22

1...9999 1

Proportional band 2 (cooling) in phys. dimensions (e.g. °C),

2. parameter set

100

Ti22

0,1...9999

Integral action time 2 (cooling) [s], 2. parameter set

180

Ti12

0,1...9999

Integral action time 1 (heating) [s], 2. parameter set

180

Td12

0,1...9999

Derivative action time 1 (heating) [s], 2. parameter set

180

Td22

0,1...9999

Derivative action time 2 (cooling) [s], 2. parameter set

180

SEtP

Name

Value range Description

Default

SP.LO

-1999...9999

Set-point limit low for Weff

-100

SP.Hi

-1999...9999

Set-point limit high for Weff

1200

SP.2

-1999...9999

Set-point 2.

0

r.SP

0...9999

Set-point gradient [/min]

OFF

SP

-1999...9999

Set-point (only visible with 8800/8840 configurator!)

0

SP.LO and SP.Hi should be within the limits of rnGH and rnGL see

configuration r Controller page17

InP.1

Name

Value range Description

Default

InL.1

-1999...9999

Input value for the lower scaling point

0

OuL.1

-1999...9999

Displayed value for the lower scaling point

0

InH.1

-1999...9999

Input value for the upper scaling point

20

OuH.1

-1999...9999

Displayed value for the lower scaling point

20

t.F1

0,0...9999

Filter time constant [s]

0,5

Etc.1

0...100 (°C)

32...212 (°F)

External cold-junction reference temperature (external TC)

OFF

InP.2

Name

Value range Description

Default

InL.2

-1999...9999

Input value for the lower scaling point

0

OuL.2

-1999...9999

Displayed value for the lower scaling point

0

InH.2

-1999...9999

Input value for the upper scaling point

50

OuH.2

-1999...9999

Displayed value for the upper scaling point

50
