Configuration level
8800 process controller
41
Configuration parameters
Name
Value range Description
Default
Y.1
Controller output Y1 (only visible when O.TYP=0)
0
0
not active
1
active
Y.2
Controller output Y2 (only visible when O.TYP=0)
0
0
not active
1
active
Lim.1
Limit 1 signal (only visible when O.TYP=0)
0
0
not active
1
active
Lim.2
Limit 2 signal (only visible when O.TYP=0)
0
0
not active
1
active
Lim.3
Limit 3 signal (only visible when O.TYP=0)
0
0
not active
1
active
dAc.A
Valve monitoring (DAC) (only visible when O.TYP=0)
0
0
not active
1
active
LP.AL
Interruption alarm signal (LOOP) (only visible when
O.TYP=0)
0
0
not active
1
active
HC.AL
Heat current alarm signal (only visible when O.TYP=0)
0
0
not active
1
active
HC.SC
Solid state relay (SSR) short circuit signal (only visible
when O.TYP=0)
0
0
not active
1
active
FAi.1
INP1 error (only visible when O.TYP=0)
0
0
not active
1
active
FAi.2
INP2 error (only visible when O.TYP=0)
0
0
not active
1
active
FAi.3
INP3 error (only visible when O.TYP=0)
0
0
not active
1
aktiv
Out.0
-1999...9999
Scaling of the analog output for 0% (0/4mA or 0/2V, only
visible when O.TYP=1..5)
0
Out.1
-1999...9999
Scaling of the analog output for 100% (20mA or 10V, only
visible when O.TYP=1..5)
100
