Configuration level
Configuration parameters 44 8800 process controller
Name Value range Description Default
Err.r Reset of all error list entries 0
0 no function (switch-over via interface is possible)
2 DI1 switches
3 DI2 switches (only visible with OPTION)
4 DI3 switches (only visible with OPTION)
5 è - key switches
6 Ò - key switches
Pid.2
Switching of parameter set (Pb, ti, td) 0
0 no function (switch-over via interface is possible)
2 DI1 switches
3 DI2 switches (only visible with OPTION)
4 DI3 switches (only visible with OPTION)
5 è - key switches
I.Chg
Switching of the actual process value between Inp1 and X2 0
0 no function (switch-over via interface is possible)
2 DI1 switches
3 DI2 switches (only visible with OPTION)
4 DI3 switches (only visible with OPTION)
5 è - key switches
di.Fn
Function of digital inputs (valid for all inputs) 0
0 direct
1 inverse
2 toggle key function
fDI1 Forcing di1 (only visible with 8800/8840 configurator!) 0
0 No forcing
1 Forcing via serial interface
fDI2 Forcing di2 (only visible with 8800/8840 configurator!) 0
0 No forcing
1 Forcing via serial interface
fDI3 Forcing di3 (only visible with 8800/8840 configurator!) 0
0 No forcing
1 Forcing via serial interface
othr
Name Value range Description Default
bAud
Baudrate of the interface (only visible with OPTION) 2
0 2400 Baud
1 4800 Baud
2 9600 Baud
3 19200 Baud
Addr 1...247 Address on the interace (only visible with OPTION) 1
