Configuration level
8800 process controller 45 Configuration parameters
Name Value range Description Default
PrtY Data parity on the interface (only visible with OPTION) 1
0 no parity (2 stop bits)
1 even parity
2 odd parity
3 no parity (1 stopbit)
dELY
0...200 Delay of response signal [ms] (only visible with OPTION) 0
O2 Entering parameter for O
2
in ppm or % 0
0 Parameter for O
2
-function in ppm
1 Parameter for O
2
-function in %
Unit Unit 1
0 without unit
1 °C
2 °F
dP Decimal point (max. number of digits behind the decimal
point)
0
0 no digit behind the decimal point
1 1 digit behind the decimal point
2 2 digits behind the decimal point
3 3 digits behind the decimal point
LED
Function allocation of status LEDs 1 / 2 / 3 / 4 0
10 OUT1, OUT2, OUT3, OUT4
11 Heating, alarm 1, alarm 2, alarm 3
12 Heating, cooling, alarm 1, alarm 2
13 Cooling, heating, alarm 1, alarm 2
14 Bus error
20 Y1, Y2, track1, track2
21 Y2, Y1, track1, track2
22 track1, track2, track3, track4
dISP 0...10 Display luminosity 5
C.dEl 0..200 Modem delay [ms]
Additional delay time, before the received message is
evaluated in the Modbus. This time is required, unless
messages are transferred continuously during modem
transmission.
0
dP.AD 0...126 Profibus address 126
bc.up
Behaviour as backup controller 0
0 No backup functionality
1 With backup functionality
FrEq Switching 50 Hz / 60 Hz (only visible with 8800/8840
configurator!)
0
0 50 Hz
1 60 Hz
ICof Block controller off (only visible with 8800/8840
configurator!)
0
0 Released
1 Blocked
