Instruction Manual Salt 6
5
3 PREPARATION
3.1 Inserting & Removing Rubber Boot
1) To remove meter from rubber boot, push
out from the bottom edges of meter until it
is completely out of boot. Ensure that the
cables of Conductivity electrode or
temperature probe are not connected.
2) To insert meter into rubber boot, slide in
from the top of meter before pushing the
bottom edges of meter down to set it into
position. Lift up the stand at the back of
meter for bench top applications if
necessary.
3.2 Inserting the Batteries
The battery compartment is found at the
back of instrument as shown. To open the
battery compartment:
3) Push in the direction of arrow
and lift up the cover.
4) Note the polarity of battery
before inserting into position.
5) After replacement, place cover
back and press down until it
locks tight.
