User’s Manual
40
Figure 59 — Storage screen.
Highlight the box beside Disk Bad Notify, and press the
button. Select percentage level of bad disk sectors at which
you want the DVR to trigger an alert. Percentage levels range
from 10% to 90%.
Highlight the box beside Disk Almost Full Notify, and press
the
button. Select the percentage level of disk usage at
which you want the DVR to trigger an alert. Percentage levels
range from 80% to 99%.
Highlight the first box beside Disk S.M.A.R.T., and press
the button. Use the Up and Down arrow buttons to scroll
through the numbers. Refer to the hard disk drive
manufacturer’s documentation for the correct temperature
setting. If the temperature of hard disk drive exceeds the
defined threshold, the system triggers an alert.
Highlight the second box beside Disk S.M.A.R.T., and press the
button. Select either ºC (Celsius) or ºF (Fahrenheit),
and press the button.
Highlight the Actions tab, and the System Event Actions screen displays.
Figure 60 — System Event Actions screen
The DVR can be set to react to system events. System events
can be associated with an Alarm-Out connector, sound the
DVR’s internal buzzer, and/or notify a number of different
devices.
Highlight the Alarm-Out box beside the desired event (Check
Recording
, Check Alarm-In, Disk Almost Full, Disk Full,
Disk Bad , Disk Temperature, or Disk S.M.A.R.T.), and
press the button. A list of Alarm Outputs appears. You
can associate as many Alarm-Outs with the Event as you wish.
If the DVR detects that event, it triggers output signals on all
the associated Alarm-Out connectors. You can also have the
DVR’s internal buzzer sound if an event is detected.
NOTE: Alarm-Out action cannot be set to System and Panic Record events.
Highlight the Notify box beside the desired event (System, Panic Record, Check Recording, Check Alarm-In,
Disk Almost Full
, Disk Full, Disk Bad, Disk Temperature, or Disk S.M.A.R.T.), and press the button. You
can toggle the entire list On and Off by highlighting Notification and pressing the button. You can toggle the
individual items On and Off by highlighting that item and pressing the button. Highlight OK and press the button
to accept your changes.
NOTE: Mail notify is the only option available for the System event.
For the Notify action to work, the DVR should be registered in the REVO Remote Pro (Remote
Administration System).
Event Status
Highlight Event Status in the Event menu and press the button. The Event Status screen appears.
