User’s Manual

Selecting ADSL (with PPPoE) allows you to set up the ADSL
network.

Highlight the box beside ID and press the

button. A

virtual keyboard appears allowing you to enter the ID for
ADSL connection.

Highlight the box beside Password and press the

button.

A virtual keyboard appears allowing you to enter the password
for ADSL connection.

NOTE: Entering the ID and Password and highlighting OK

reads the current IP address of the DVR configured
by the ADSL network.

NOTE: If the DVR is configured for DHCP or an ADSL network, the IP address of the DVR might change whenever

the unit is turned on.

Highlight the DVRNS tab, and the DVRNS screen displays.

NOTE: The DVRNS (DVR Name Service) allows you to connect to the DVR, via internet, with the dynamic IP

address or the domain name. To make this feature easy, you can name your DVR (example: TomStore05)
and connect using the DVR name instead of the IP address. To use the DVRNS feature, you will need
to have your DVR registered through DVRNS with the settings matched between your DVR and the DVRNS
server. Any changes to the DVRNS server might cause improper operation.

Figure 20 — DVRNS setup screen.

Highlight Use DVR Name Service and press the

button

to toggle between On and Off.

Highlight the box beside DVRNS Server and press the

button. A virtual keyboard appears allowing you to enter the
IP address or domain name of the DVRNS server.

NOTE: You will need to get the IP Address or domain

name of the DVRNS Server from your network
administrator.

NOTE:

You can use the domain name instead of IP

address if you already set up the DNS Server
when setting up the LAN.

Highlight the box beside Port and press the

button. Set the port number of the DVRNS server using the Up and

Down

arrow buttons to increase or decrease the numbers.

Highlight Use NAT and press the button to toggle between On and Off.

NOTE: When using the NAT (Network Address Translation) device such as a router, refer to the NAT manufacturer’s

instructions for the proper network settings.

Highlight the box beside DVR Name and press the

button. A virtual keyboard appears allowing you to enter the

DVR name to be registered on the DVRNS server.

Highlight the Check box and press the button to check whether or not the name you entered can be used.

NOTE: The DVR name you entered should be checked by selecting Check, otherwise the DVRNS changes will

not be saved.

When entering no name or a name already registered on the DVRNS server, an error message displays.

Highlighting Save and pressing the button registers the DVR on the DVRNS server. Proper DVRNS settings will
display the help desk information of the DVRNS server in the box beside Help Desk.

Highlight the REVO Remote tab, and the REVO Remote screen displays.
