82 Chapter 3
Using E5810A Web Access
Viewing and Modifying Configuration
Modifying E5810A Configuration
To modify the current E5810 configuration, from the Current Configuration of
E5810 LAN/GPIB Gateway page, click the Modify Configuration button at the
top or the bottom of the page to display the Password dialog box.
Displaying the
Configuration Page
If the default password (E5810) is set as the current password, asterisks
(*****) appear in the window. In this case, just click the
Submit button to
display the Configuring your E5810 LAN/GPIB Gateway page (see the figure
on the next page). If no asterisks appear, enter the current E5810 password
and then click the
Submit button.
When the Configuring your E5810 LAN/GPIB Gateway page is displayed, you
can configure desired parameters by typing or selecting the new value in the
Edit Configuration column and then clicking the Save button and then the
Reboot E5810 button at the top or the bottom of the page. See the figure on
the next page for a typical display.
Although there are a few exceptions, most changes to configuration
parameters are not effective until the
Save button is clicked and then the
Reboot E5810 button is clicked.
NOTE
If you do not know the current E5810 password, you can temporarily
reset the password to the default (E5810) by pressing the
Preset button
on the front panel of the E5810.
