Chapter 2 53
Installing the E5810A
Installing the E5810A on an Enterprise Network
After connecting the E5810 to the Enterprise network, plug the E5810 AC
power cord into an AC outlet and observe the power-on sequence. When
the power-on sequence is complete, the assigned IP address of the E5810
is displayed on the second line of the front panel display. A typical display
follows. See
Chapter 1 , “E5810A Description” for power-on sequences.
Configuring the E5810A for Enterprise Network
Operation
After the E5810 is installed on the Enterprise network, you can check or set
(as required) E5810 configuration parameters using the E5810 Web access
that is accessed from your Web browser (Internet Explorer 6.0 or greater).
The steps to set E5810 configuration parameters are:
1 Display the Welcome Page. To display the E5810 Welcome page, from
your Web browser address line, type
‘http://
’ , where is
the IP address displayed on the E5810 front panel display. Then, press
the
Enter key.
NOTE
The Mains disconnect for the E5810 is to unplug the AC power cord from
the AC outlet. The E5810 has no AC Power switch.
IP Address and Hostname Displayed
Display shows IP address (and Hostname, if known)
Activity
LAN GPIB RS232 Power Fault
Preset
E5810A
LAN/GPIB Gateway
Hostname
169.254.58.10
