OPERATION
5
29
OPTISYS CL 1100
www.krohne.com 01/2013 - 4002492301 - MA OPTISYS CL 1100 R02 en
After activating the manual hold function and the preparative measures, you can get access to
the calibration procedure from the measuring mode in two different ways. Either you go via the
main menu setup (Step 3a) or via the main menu quick setup (Step 3b):
Step 3a: accessing the calibration menu via the main menu "setup"
You can start the calibration procedure now as described in "Step 4".
Step 3b: accessing the calibration menu via the main menu "quick setup"
You can start the calibration procedure now as described in "Step 4".
Press > for more than 2.5 seconds, then release the button. You are on the main menu level. In the upper
line of the display "A" appears, beneath the main menu quick setup is highlighted.
Press or until the main menu setup is highlighted.
MAIN MENU
A quick setup
B test
> C setup
D service
Press > to enter the chosen menu.
You are on the first submenu level. In the upper line of the display "setup"
and "C1" appears, beneath the submenu process input A is highlighted.
Press > to enter the chosen menu.
You are on the second submenu level. The submenu
parameter is highlighted.
Press > to enter the chosen menu.
Press or to select Cl
2
for calibrating the
free chlorine measurement, ClO
2
for calibrating
the chlorine dioxide measurement or O
3
for
calibrating the ozon measurement.
Press ^ to confirm the entered value.
Press or until the submenu product cal. is
highlighted.
Press > for more than 2.5 seconds, then release the button. You are on the main menu level. In the upper
line of the display "A" appears, beneath the main menu quick setup is highlighted.
MAIN MENU
> A quick setup
B test
C setup
D service
Press > to enter the chosen menu.
You are on the first submenu level. In the upper line of the display "quick
setup" and "A" appears, beneath the submenu language is highlighted.
Press or until the submenu product cal. A is highlighted.
Press > to enter the chosen menu.
