5
OPERATION
18
OPTISYS CL 1100
www.krohne.com 01/2013 - 4002492301 - MA OPTISYS CL 1100 R02 en
5.2 Function tables
5.2.1 Menu A, quick setup
A9, process input A product calibration (Cl
2
/ClO
2
/O
3
)
A12, process input B REDOX calibration
A13, process input B pH calibration
Measuring
mode Main menu Submenu Parameter
3 or 4
pages,
scrolling
with ↓ or ↑
> 2.5 s
^
C setup >
^
C1 process input
A
>
^
C1.1 parameter >
^
For further
information
see function
tables.
C1.9 slope
C1.11 pH compensation
C1.13 cleaning
C1.14 time constant
C1.15 temperature
C1.18 product cal.
C2 process input
B (for 2 channel
version; refer to
pH/ORP sensor
manual for
further
information)
C2.1 parameter (pH/REDOX)
C2.7 inner buffer (only pH)
C2.8 zero point
C2.9 slope
C2.10 calibration buffer (only
pH)
C2.14 time constant
C2.15 temperature (only pH)
C2.16 REDOX cal.
C2.17 pH cal.
↓↑ ↓↑ ↓↑ ↓↑
INFORMATION!
Note that the appearance of some sub-menus depends on the hardware setting and the used
sensor(s). Also only the sensor relevant menus and submenus are shown here in detail. For all
other menu functions refer to the MAC 100 documentation .
For 1 or 2 channel version: Settings for sensor calibration
For 2 channel version; refer to pH/ORP sensor manual for further information.
Only if switched to ORP!
For 2 channel version; refer to pH/ORP sensor manual for further information.
