5.1 Menu mode structure
INFORMATION!
The following table just presents an overview. When programming the device, always consult the
function tables additionally as they contain further information!
Only the sensor relevant menus are shown in the following tables. For detailed information
about the general setting refer to the signal converter manual.
Measuring
mode Main menu Submenu Parameter
3 or 4
pages,
scrolling
with ↓ or ↑
> 2.5 s
^
A quick setup >
^
A9 product cal.A
process input A
product
calibration
(Cl
2
/ClO
2
/O
3
)
>
^
A9.1 temp.comp. >
^
For further
information
see function
tables.
A9.4 pH compensation
A9.6 start calib.
A9.7 stored value
A9.8 reference
A12 REDOX
calibration B
Only if switched
to ORP!
process input B
REDOX
calibration (for 2
channel version;
refer to pH/ORP
sensor
documentation
for further
information)
A13 pH cal. B
process input B
pH calibration
(for 2 channel
version; refer to
pH/ORP sensor
documentation
for further
information)
A13.1 temp.comp.
↓↑ ↓↑ ↓↑ ↓↑
> 2.5 s
^
B test >
^
B1 sim.process
inp.A
>
^
B1.1 temperature >
^
For further
information
see function
tables.
B1.4 conc.absolute
B2 sim.process
inp.B
B2.1 temperature
B2.5 REDOX/ORP
Only if switched to ORP!
(for 2 channel version; refer to
pH/ORP sensor documentation
for further information)
B2.7 pH
(for 2 channel version; refer to
pH/ORP sensor manual for
further information)
B3 simulation I/O B3.1 current out A
B3.2 current out B
B3.3 current out C
B3.6 simulation R3 off
