Chapter 2
Product Overview
ReadyBoard 700
Reference Manual
11
Connector Definitions
Table 2-2 describes the connectors shown in Figures 2-3 to 2-5. All I/O connectors use 0.1” pin spacing
unless otherwise indicated.
Table 2-2. Connector Descriptions
Jack #
Signal/Device
Description
BTI
RTC battery (B1)
2-pin, 1.25 header for battery input
DIMM1
SODIMM
144-pin socket for SDRAM SODIMM
J1
Fan connector
3-pin header provides +12v, tach, and ground to fan.
J2
GPIO
10-pin, 2mm connector
J3
Serial 3 & 4
20-pin, 2mm connector for serial ports 3 & 4
J4
Power In
4-pin, 0.2” (5.08mm), connector for input power +5V, +12V, GND
J5A/B
Serial 1 & Serial 2 9-pin dual connectors for Serial Ports 1 & 2 (DB9)
J6
Power On
3-pin, 2mm header for Suspend and Power On voltages
J7
Video (LVDS)
20-pin, 1.25mm, connector for LVDS video display
J8
Video (CRT
VGA)
15-pin connector for output to a CRT monitor
J9
Video (LCD/TTL) 50-pin, 1mm connector 36-bit output for LCD panels
J10
Ethernet 1 + LEDs 14-pin connector for 8-pin RJ45 and LEDs for Ethernet port 1
J11
Ethernet 2 + LEDs 14-pin connector for 8-pin RJ45 and LEDs for Ethernet port 2
J12
PC/104-Plus
120-pin, 2mm, connector for PCI bus
J13A/J13B &
J14C, J14D
PC/104 bus
104-pins for PC/104 connector
64 pins = J13 and 40-pins = J14
J15A/B
USB 0 & 1
8-pin connector provides USB0 and USB1
J16
Keyboard/Mouse
6-pin, 2mm PS/2 Keyboard/Mouse connector (dual output cable)
J17
IrDA
5-pin header for IrDA signals
J18
Utility
5-pin header for external Battery, Reset, Speaker
J19
Audio In/Out
16-pin, 2mm connector for Line In L/R, Line Out L/R, Mic in
J20
Floppy/Parallel
Port
26-pin, 2mm connector for parallel port interface
J21
USB 2 & 3
10-pin, 2mm connector provides USB2 and USB3 output
J22
Primary IDE
44-pin, 2mm connector for the primary IDE interface
J23
CompactFlash
(Secondary IDE)
50-pin socket accepts Type 1 or Type II CompactFlash cards
Switch Definition
Table 2-3. Reset Switch (SW1)
Component
Description
SW1 Reset switch
4-pin, 5V, Momentary push button switch
