PSP SERIES
USER MANUAL
v
The wire which is coloured Brown must be connected to the
terminal marked with the letter L or P or coloured Brown or Red.
If in doubt, consult the instructions provided with the equipment
or contact the supplier.
This cable/appliance should be protected by a suitably rated and
approved HBC mains fuse: refer to the rating information on the
equipment and/or user instructions for details. As a guide, cable of
0.75mm 2 should be protected by a 3A or 5A fuse. Larger
conductors would normally require 13A types, depending on the
connection method used.
Any moulded mains connector that requires removal /replacement
must be destroyed by removal of any fuse & fuse carrier and
disposed of immediately, as a plug with bared wires is hazardous if
a engaged in live socket. Any re-wiring must be carried out in
accordance with the information detailed on this label.
PSP SERIES
USER MANUAL
1
1. Product Introduction
The PSP series is a programmable switching power supply with backlit
liquid crystal display built to the latest technological standards.
Construction is in accordance with VDE 0411 = EN 61010. Moreover, the
PSP series has been EMV-tested and fulfils the requirements of the
applicable European and national directives. Conformance to these has
been proven; the relevant statements and documents are lodged with the
manufacturer.
Note: This is a Class A device which can cause RF
interference within the home.
To maintain this condition and to guarantee safe operation, the user
must observe these operating instructions without fail.
Application Note
z Connection of low-voltage loads to the marked connection sockets
provided for this purpose and their operation at a voltage between 0 to
rating voltage.
z The current consumption of a connected load may not exceed rating
current.
z The Switching Power Supply PSP series is suitable for connection to
115 or 230 V 50/60 Hz AC power sockets.
z Operation must not take place under unfavorable ambient conditions
including:
-Moisture or excessive air humidity.
-Dust and combustible gases, fumes or solvents.
