Installation
AFG APP Installation
The AFG-125/225 modules require a separate APP
installation.
1. Load the AFG.gz APP file onto a USB flash drive.
Insert the USB flash drive into the USB slot on the
front panel.
2. Press Utility > File Utilities. Select the AFG.gz
file on the USB flash drive.
3. Press  twice to install the AFG APP.
4. After the installation has completed, restart the
oscilloscope.
Installing the DS2-FH1
The DS2-FH1 consists of 2 housings that are attached
to the feet on the underside of the case.
1. Slip the housing over the front of the feet on the
GDS-2000A.
2. Make sure that the rear tab clips securely over the
fan vent grid on the rear panel, as shown below.
1
2
