O
VERVIEW
The AFG-125/225/125P/225P are arbitrary function
generator modules for use with the GDS-2000A series
DSOs. The options require the DS2-FH1 module
extension bay to secure the module to the DSO. This
Quick Start Guide gives a quick overview to the
features, installation and basic operation for the AFG-
125/225/125P/225P. See the user manual for further
details.
The AFG-125P & 225P also incorporate a power supply
output with a selectable voltage output of 2.5, 3.3 or 5V.
The AFG-125/225/125P/225P are only supported with
GDS-2000A series DSOs with firmware version V1.19 or
above installed.
Main Features
Waveforms • Sine, Square, Ramp, Pulse, Noise,
ARB waveforms
ARB Features • 4k memory/waveform length
• 10 bit amplitude resolution
Features • 1uHz ~ 25MHz max.
• AM, FM, PM, FSK, SUM
modulation
• Sweep function
• Burst function
• Channel tracking, coupling (AFG-
225)
• 50Ω and high load impedance
• Internal / Manual trigger
